Theory sb25aw

All-Weather Dual 5" Multi-Use Surface Mount Loudspeaker - Black

Theory sb25aw

All-Weather Dual 5" Multi-Use Surface Mount Loudspeaker - Black
$1,395.00
Select Color:


Overview

All-Weather Jack of All Trades

You have never had such a compact and capable loudspeaker in your system design toolbox before.

The Theory sb25aw is an all-weather, 4-ohm or 70V/100V, version of the remarkable sb25 indoor surface mount loudspeaker.

Like the sb25, the sb25aw is a wide-bandwidth, high-output multi-use loudspeaker, perfect for restaurants, bars, hotels, retail stores, houses of worship and anywhere high-resolution, high-fidelity background or foreground sound is needed. The sb25aw incorporates a durable perforated stainless steel grille, water-tight loudspeaker wire entry point, selectable hi-z or low-z operating modes, and has an optional yoke mounting bracket available.

Capable of astonishing range and output, the 3.8” deep sb25 is literally a jack of all trades and will have you rethinking how you incorporate sound in your next high-value project.

Details & Specs

Model Theory sb25aw
Description High-Output Weather Resistant Surface Mount Loudspeaker
Operation Passive, Requires 1 Theory Loudspeaker Controller Amp Channel
4-ohm or 70V/100V Operation, Selectable
DSP Requirements Requires Model-Specific Theory-Certified DSP Loudspeaker Processing
Drivers 2 x 5" Theory Carbon Fiber Low Frequency Drivers
1 x 1.4" Theory Advanced Polymer High Frequency Compression Driver
Enclosure Powder Coated and Anodized Extruded and Machined Aluminum, Perforated Aluminum Grille
Terminals Euroblock Connector with Parallel Output
Outdoor Capability Indoor and Outdoor Use
Mounting Points Two Theory VersaSlot T-Slots Running Full Height with 4 x M5 Captive Nuts
Included Z-Clips
Optional Yoke Bracket, Universal Mount Adapter, and Table Top Stand
Bandwidth 54Hz -23kHz, -6dB
46Hz-24kHz, -10dB
Coverage 125 Degrees Conical
160 Degrees Conical (-12dB @ 10kHz)
Sensitivity 94dB (LF); 108dB (HF) SPL/2.83V/1m
Power Handling 200W (AES)
400W (Continuous)
800W (Peak)
Minimum Recommended Power 50W rms
Maximum Output 117dB SPL / 1m (based on AES power rating)
123dB SPL / 1m (peak)
Nominal Impedance 4-ohms; Hi-Z (70V/100V) Selectable
Transformer Taps 60W, 30W, 15W, (7.5W, 70V)
Colors Black, White
Dimensions 21.5" H x 9.5" W x 3.8" D (546mm H x 241mm W x 97mm D)
Total Installed Depth (Z-clip Mount) 3.93" D (100mm) Including Z-Clip Mounting Brackets
Net Weight 24.5 lbs. (11.1 kg)
Included Accessories Theory Z-Clip Mounting Brackets (male and female) for Flat Surface Mounting
sb25aw Waterproof Terminal Cover
Optional Accessories sb25aw Yoke Bracket
sb Table Top Stand
sb25 Universal Mount Adapter
Mount Hole Patterns: 75mm and 100mm VESA Square, 2.0” x 4.25” 1/4”-20 and 2.75” x 5.0” 1/4”-20 Threads, Mount Hole for 1/2" Rigid Conduit Hub (1/2" conduit mount)
Compatible 3rd Party Mounts Omnimount 25.0W Wall Ball Mount
Omnimount 25.0C Ceiling Ball Mount
Adaptive Technologies Multimount MM-016-BT Wall Multi-Mount
Adaptive Technologies Multimount MM-017 Wall Pan-Tilt
Adaptive Technologies Multimount MM-018 Ceiling Pan-Tilt
