Item #1090000072

Paradigm CI Elite E65-R V2

6.5" In-Ceiling Speaker
Item #1090000072

Paradigm CI Elite E65-R V2

6.5" In-Ceiling Speaker
$549.99
Starting at $46/mo or 0% APR with . Check your purchasing power
More on the way! Order now to reserve risk free.

Overview

The Paradigm CI Elite is the custom installer’s performance-oriented solution. The CI Elite series is Made in Canada and has all the technology advantages of Paradigm's CI PRO Series, but they didn’t stop there. It’s packed full of features that make a difference, and it doesn’t get much sweeter than this when looking for the ultimate sound performance.

Aluminum Magnesium Ceramic (AL-MAC) Tweeter with Exclusive Perforated Phase-Aligning (PPA) Tweeter Lens

AL-MAC is Paradigm's unique blend of Aluminum, Magnesium, and Ceramic materials; each of which contribute to the end goal of greater accuracy and realism. Their special properties contribute to the final product which is not only strong and lightweight, but embodies a natural anti-resonance to ensure the tweeter doesn’t just sound good “on paper” but truly sounds incredible in the real world.

Aluminum Magnesium (AL-MAG) Cones

Similar to the goals Paradigm had in mind when developing the AL-MAC tweeter, AL-MAG was conceived to bring the same elevated level of performance to the area where your ears are the most sensitive. In addition, AL-MAG combines a high stiffness-to-mass ratio with superior internal damping for greater accuracy.

Advanced Shock-Mount System

This system mechanically decouples the die-cast aluminum baskets from the specially formulate CARBON-X ingrained baffles reducing performance-robbing vibrations and resonance between the chassis and the acoustic platform. Without these resonances, all drivers are left free to deliver pure, unaltered sound with no audible distortion.

Oversized, 1.5” High-Power Handling Voice Coil

Paradigm CI Elite's motor structure dramatically increases maximum output level and reduces power compression.

Patented† Active Ridge Technology (ART) Surrounds

Made in-house and over-moulded directly onto each cone, ART surrounds achieve greater excursion for a 3dB gain in distortion-free output (50% greater) compared to drivers with standard surrounds. † US patents: D654,479S and 8,340,340B2.

Advanced Features for a Solid and Secure Installation

  • FEA-Optimized Ultra Rigid Cast-Aluminum Baskets feature integrated heat sinks for higher power handling, for better bass, better dynamics, and less power compression.
  • Rear Component Shielding protects internal parts from debris. The polycarbonate material creates an installation that will not warp. Flat covers also make it easy to lie speakers down during the installation process without tipping. (CI Pro/Elite Models Only)
  • Pocketed screw holes help to hold the drill steady, making installation a snap.
  • Premium-grade components include high-power rated resistors, capacitors and heavy gauge wire inductors.
  • Nickel-plated, spring loaded binding posts feature a larger wire hole to accept higher-gauge wire or banana plugs.
  • Bezel-Free Micro-Perf Grilles offer a clean aestetic from room-to-room.
  • Magnetically attached grilles: neodymium magnets hold grilles firmly in place.

Partnered with the NRC

Paradigm is partnered with Canada’s world-renowned NRC in ongoing research to reveal the true nature of sound and human hearing. Findings influence design and performance specs, resulting in a uniquely realistic listening experience, backed by sound science.

Details & Specs

Model Paradigm CI Elite E65-R v2
Design 2-driver, 2-way in-ceiling, Advanced SHOCK-MOUNT System, Ultra-Rigid CARBON-X Baffle
Crossover 3rd-order electro-acoustic at 2.0 kHz
High Frequency Driver 1” (2.5cm) Aluminum Magnesium Ceramic (AL-MAC) Tweeter with Exclusive Perforated Phase-Aligning (PPA) Tweeter Lens and Reduced Edge Diffraction (RED) Technology
Frequency Response On-Axis ±3 dB from 75 Hz - 22 kHz
Frequency Response 30° Off-Axis ±3 dB from 75 Hz - 18 kHz
Mid/Bass Frequency Driver 6.5” (16.5cm) Aluminum Magnesium (AL-MAG) Cones with overmolded Active Ridge Technology (ART) surround, Advanced Shock-Mount System, 1.5” high-temp voicecoil, FEA-Optimized Ultra Rigid Cast- Aluminium Baskets
Sensitivity Room / Anechoic 92 dB / 88 dB
Low Frequency Extension 39 Hz
Suitable Amplifier Power Range 15-150 W
Maximum Input Power 100 W
Impedance Compatible with 8 ohms
Cut-Out Dimensions 7-3/4” (19.7cm) dia.
Minimum Mounting Depth
(Depth required is the distance between 1/2" drywall, or similar material)
3-5/8” (9.2cm)
Dimensions
(h x w x d, including grille)
8-7/8” (diameter) x 4-1/4” (depth) (22.6cm x 10.7cm)
Weight 5.7 lbs (2.6 kg)
Finishes White, paintable grille, black speaker
