Kaleidescape Strato Prime Bundles

Compact/Terra Prime Bundles with Strato V Player + Movie Store Credits

Kaleidescape Strato Prime Bundles

Compact/Terra Prime Bundles with Strato V Player + Movie Store Credits
Was $9,190.00 From $8,990.00
Save $200
Contact Us

Overview

Terra Prime movie servers feature an all-new board design, faster processing power, and a faster network. Offering faster downloads than its predecessor, with the highest capacity. Terra Prime adds increased performance and storage capabilities.

Terra Prime Solid-State is the fastest and quietest movie server available, the ideal choice for marine and state-of-the-art installations.

Terra Prime stores movies, TV series, and concerts on an array of enterprise-class high-capacity hard drives or data center grade solid-state drives. Content stored on the movie server is played back on Strato players.

The new Terra Prime Solid-State is the only dedicated movie server with 2.5 Gigabit Ethernet enabling the fastest downloads and the most simultaneous movie playbacks.

Made in the USA, Kaleidescape movie servers are custom designed and manufactured for reliable, premium performance.

Kaleidescape’s operating system (kOS) is custom developed, managed, and controlled internally, with automatic updates, providing the best experience of any movie server on the market.

Key Features - All Models

  • 2.5 Gigabit Ethernet
  • Kaleidescape 4K movies have lossless audio and reference video
  • All movies are stored securely and protected by cloud backup
  • Movies can be downloaded on up to five systems; perfect for multiple residences
  • Terra movie servers enable large configurations
  • Up to four Terra servers can be combined for more storage
  • Custom rack mounts sold separately

Key Features w/ High-Capacity Hard Drives (HDD)

  • Next-generation movie server with high capacity
  • Enterprise-class hard disk drives
  • Downloads a Kaleidescape high-bitrate 4K movie in as little as eight minutes
  • Distributes up to 5 simultaneous playback streams (compact)
  • Distributes up to 10 simultaneous playback streams (full-size)

Key Features w/ Solid-State Drives (SSD)

  • Next-generation movie server with ultimate performance
  • Data center grade solid-state drives
  • Low power, quiet operation
  • Storage options for approximately 500 (31TB) or 125 (8TB) 4K movies
  • Downloads a Kaleidescape high-bitrate 4K movie in as little as four minutes
  • Distributes up to 25 simultaneous playback streams

Details & Specs

Model Terra Prime HDD
Shared Specifications
Movie Server Downloads Kaleidescape high-bitrate 4K movies in as little as 8 minutes
Compact serves up to 5 simultaneous playbacks of Kaleidescape 4K movies
Full-size serves up to 10 simultaneous playbacks of Kaleidescape 4K movies
Network 2.5 Gigabit Ethernet (recommended)
1 Gigabit Ethernet (minimum)
Other Connection USB 3.0 (reserved)
Environment Operating: 41 to 95°F (5 to 35°C)
Storage: -4 to 140°F (-20 to 60°C)
Relative humidity: 20 to 80% (operation), 5 to 90% (storage)
Maximum operating altitude: 10,000ft (3,048m)
Ventilation Airflow:
Full Size - 10 CFM (17 m3/hr) max
Compact - 5 CFM (8.4 m3/hr) max
Minimum 1" (2.5cm) space at the front
Minimum 2" (5cm) space at the rear
Certifications CSA 62368-1
IEC 62368-1
FCC CLASS B
CE
RoHS Compliant
Full Size - 96, 72, & 48 TB
Dimensions (WxHxD) 17.0 x 3.5 x 10.0"
43.2 x 8.9 x 25.4 cm
Weight 15.4 lb (7.0 kg) with no drives installed
21.6 lbs (9.8 kg) with four hard drives
Fan & Drive Noise Typical: 29 dB(A)
Power Max consumption: 48W
Typical: 43W
External power adapter:
2.6 x 1.4 x 6.5" (6.6 x 3.5 x 16.5 cm)
150W with detachable line cord
100-240V, 50-60Hz universal input
12VDC @ 12.5A
Storage 96TB configuration stores:
~1,600 Kaleidescape high-bitrate 4K movies
72TB configuration stores:
~1,200 Kaleidescape high-bitrate 4K movies
48TB configuration stores:
~800 Kaleidescape high-bitrate 4K movies
Rack Mount (sold separately) Rack shelf available for mounting one unit in a 19" rack
2RU space
Compact - 24 & 8 TB
Dimensions (WxHxD) 7.87 x 1.52 x 14.33"
20.0 x 3.9 x 36.4 cm
Weight 7.2 lbs (3.3 kg)
Fan & Drive Noise Typical: 25 dB(A)
Power Max consumption: 29W
Typical: 24W
External power adapter:
2.6 x 1.4 x 6.5in (6.6 x 3.5 x 16.5 cm)
150W with detachable line cord
100-240V, 50-60Hz universal input
12VDC @ 12.5A
Storage 24TB configuration stores:
~400 Kaleidescape high-bitrate 4K movies
8TB configuration stores:
~130 Kaleidescape high-bitrate 4K movies
Rack Mount (sold separately) Rack shelf available for mounting one or two units in a 19" rack
1RU space
Model Terra Prime Solid-State
Shared Specifications
Movie Server Downloads Kaleidescape high-bitrate 4K movies in as little as 4 minutes
Serves up to 25 simultaneous playbacks of Kaleidescape high-bitrate 4K movies
Network 2.5 Gigabit Ethernet (recommended)
1 Gigabit Ethernet (minimum)
Other Connection USB 3.0 (reserved)
Environment Operating: 41 to 95°F (5 to 35°C)
Storage: -4 to 140°F (-20 to 60°C)
Relative humidity: 20 to 80% (operation), 5 to 90% (storage)
Maximum operating altitude: 10,000ft (3,048m)
Ventilation Airflow:
Full Size - 10 CFM (17 m3/hr) max
Compact - 5 CFM (8.4 m3/hr) max
Minimum 1" (2.5cm) space at the front
Minimum 2" (5cm) space at the rear
Certifications CSA 62368-1
IEC 62368-1
FCC CLASS B
CE
RoHS Compliant
Full Size - 31 TB
Dimensions (WxHxD) 17.0 x 3.5 x 10.0"
43.2 x 8.9 x 25.4 cm
Weight 15.4 lb (7.0 kg) with no drives installed
19.8 lbs (9.0 kg) with four solid-state drives + heat sink cartridges installed
Fan Noise Typical: 21 dB(A)
Power Max consumption: 28W
Typical: 22W
External power adapter:
2.6 x 1.4 x 6.5" (6.6 x 3.5 x 16.5 cm)
150W with detachable line cord
100-240V, 50-60Hz universal input
12VDC @ 12.5A
Storage Four removable 7.68 TB solid-state TLC flash drives (30.72 TB total)
Stores:
~500 Kaleidescape high-bitrate 4K movies
~800 HD movies
~4,600 SD movies
Rack Mount (sold separately) Rack shelf available for mounting one unit in a 19" rack
2RU space
Compact - 8 TB
Dimensions (WxHxD) 7.87 x 1.52 x 14.33"
20.0 x 3.9 x 36.4 cm
Weight 6.6 lbs (3.0 kg)
Fan Noise Typical: 17 dB(A)
Power Max consumption: 22W
Typical: 16W
External power adapter:
2.6 x 1.4 x 6.5in (6.6 x 3.5 x 16.5 cm)
150W with detachable line cord
100-240V, 50-60Hz universal input
12VDC @ 12.5A
Storage One integrated 7.68 TB solid-state TLC flash drive
Stores:
~125 Kaleidescape high-bitrate 4K movies
~200 HD movies
~1,150 SD movies
Rack Mount (sold separately) Rack shelf available for mounting one or two units in a 19" rack
1RU space
