Item #FP41084

Bowers & Wilkins CCM 7.3 S2

In-Ceiling Speaker
Item #FP41084

Bowers & Wilkins CCM 7.3 S2

In-Ceiling Speaker
$2,100.00
In Stock: Free 2-Day Shipping
Contact Us

Overview

The CCM7.3 S2 is a high-performance in-ceiling speaker for outstanding performance in both theatre and stereo applications. Its sophisticated drive unit configuration features a 25mm(1in) Carbon Dome tweeter, a 100mm (4in) FSTTM Continuum cone midrange and 2 x 130mm (5in) Aerofoil Profile bass drivers. Its critically formed baffle is constructed from glass-reinforced ABS while its integrated backbox ensures easy retrofittable installation, cuts down sound transfer between spaces, and optimizes sound quality.

Drive Units

  • 1" Carbon Dome Tweeter
  • 1 x 4" Continuum Cone FST Midrange
  • 2 x 5" Aerofoil Profile Bass
  • 25 - 200W

Details & Specs

Specifications

  • Design: 3-way in-ceiling system
  • Technical Features
    • Carbon Dome tweeter
    • Continuum cone FST midrange
    • Aerofoil profile bass cones
  • Drive units
    • 1x 25mm (1") Carbon Dome high-frequency
    • 1x 100mm (4") Continuum cone FST midrange
    • 2x 130mm (5") Aerofoil profile bass
  • Frequency range (-6dB): -6dB at 52Hz and 33kHz
  • Frequency Response -3dB: 55Hz - 28kHz ±3dB
  • Sensitivity: 90dB spl (2.83Vrms, 1m)
  • Impedance Nominal (min): 8 Ohm (Minimum 3.1 Ohm)
  • Recommended amplifier power: 25W - 200W into 8 Ohm on unclipped program
  • PMK: 7C

Approximate Dimensions

  • Frame
    • Height: 14"
    • Width: 14"
  • Cutout
    • Height: 13.1"
    • Width: 13.1"
    • Height With PMK: 13.2"
    • Width With PMK: 13.2"
  • Protrusion: 0.3"
  • Depth: 7.66"

Approximate Weight

  • Unit: 19.84 lbs
  • Shipping: 23 lbs
